INCLUDED IN THE BOX
• AmpCharge Mini 45 • User Guide • Warranty Card
SPECIFICATIONS
● Input: 100-240VAC 50-60Hz 1.2A Max
● USB-C1 Output: 5A/3A; 9V/3A; 12V/3A; 15V/3A; 20V/2.25A (PD45W Max); 5-11V/3A; 5-20V/2.5A (PPS45W Max)
● USB-A Output: 5V/3A; 9V/3A; 12V/2.5A; 15V/2A; 20V/1.5A (QC3.0 30W Max)
● USB-C+A Output: 15W Max
● Dimension: 35 x 35 x 41mm
● Weight: 61g
FAQ
1. What devices can I charge with it?
It supports a wide range of devices, including smartphones (iPhone and Android), tablets, wireless earbuds, power banks, and other 45W-compatible devices.
2. Does it support fast charging?
Yes. It supports USB Power Delivery (PD 45W), PPS, and Quick Charge 3.0, enabling fast and efficient charging for supported Apple, Samsung, Google, and other devices.
3. Can I charge two devices at the same time?
Yes. The AmpCharge Mini 45 comes with 1 USB-C and 1 USB-A port, allowing you to charge two devices simultaneously with intelligent power distribution.
4. Will charging speed be affected when using both ports?
Yes, the total output is shared when both ports are used at the same time. This ensures safe and stable charging across both devices.
