INCLUDED IN THE BOX
• AmpCharge Mini 100 • User Guide • Warranty Card
SPECIFICATIONS
● Input: 100-240VAC 50-60Hz 2.0A Max
● USB-C1/C2 Output: 5A/3A; 9V/3A; 12V/3A; 15V/3A; 20V/5A (PD100W Max) ; 5-21V/5A (PPS105W Max)
● USB-A output: 5V/3A; 9V/3A; 12V/2.5A; 15V/2A; 20V/1.5A (QC3.0 30W Max)
● USB-C1+C2 Output: PD45W + PD45W (90W Max)
● USB-C1+A Output: PD45W + 30W (75W Max)
● USB-C2 + A Output: 15W Max
● USB-C1+(C2+A) Output: PD45W + 15W (60W Max)
● Dimension: 62 x 40 x 40mm
● Weight:142g
FAQ
1. What is AVS technology?
AVS (Adjustable Voltage Supply) is a next-generation feature of USB Power Delivery 3.2 that dynamically adjusts the charging voltage in small increments based on your device's requirements. This enables more precise power delivery, helping to improve charging efficiency while reducing heat generation.
2. What devices can I charge?
The AmpCharge 45 AVS is compatible with:
Smartphones
Tablets
Wireless earbuds
Smartwatches
Power banks
Gaming handhelds
USB-C laptops requiring up to 45W, including compatible MacBook Air models.
3. Does it support fast charging?
Yes. It supports: USB Power Delivery (PD) 3.2; PPS (Programmable Power Supply); AVS (Adjustable Voltage Supply); Quick Charge 3.0 (QC3.0).
4. Can it charge two devices simultaneously?
Yes. The charger features 1 USB-C and 1 USB-A port, allowing you to charge two devices at the same time. When both ports are used simultaneously, the total shared output is 15W.
